High performance for professional video editing
A professional video editing system with incredible performance. The i9-9960X processor has 16 physical cores and 32 threads for immense performance in Premier Pro. We don’t recommend increasing the processor beyond this point as higher models have more cores but run at lower clock speeds. Overall there is little performance to be gained from higher models.
There is a big step up in performance of the memory as we move from 64GB to 128GB RAM. This enables your system to perform better when processing high resolution footage especially if you plan to work with HDR content. It is always wise to leave plenty of memory headroom as if your system runs out of memory, performance is hit hard.
The GPU performance is superb due to the use of the dual Quadro P5000 graphics cards. Each card has 16GB of memory giving a staggering 32GB of video memory in total. This will allow even the most complex of editing streams in the highest resolution to be undertaken on the GPUs rather than the CPU which will improve performance tremendously.
Take a look at our blogs to find out more about how your choice of PC components affects your overall system performance in Premiere Pro.
2 x Quadro P5000 for incredible performance
128GB System Memory
Specification
Processor
- Intel Core i9-9960X 3.1Ghz 16 Core CPU,
- Max Turbo Frequency 4.5Ghz
- Cache: 22MB
- Be Quiet Silent Loop 360 Liquid Cooler Installed
Memory
- 128GB DDR4 3000Mhz RAM
- Quad Channel – 8 x 16GB
- Supports up to 128GB
- 8 x DIMM sockets (8 Used)
Hard Drive
- 512GB Samsung 970 Pro NVMe M.2 SSD
- 1TB Samsung 970 Pro NVMe M.2 SSD
- 3 x M.2 sockets, 1 free
- 2 x 12TB Seagate BarraCuda Pro 3.5″ Hard drive
- 8 SATA Ports, 5 free (3 Used for Blu Ray & 2 x 12TB HDD)
Optical Drive
- Asus BW-16D1HT Blu Ray Writer
- 2 x Optical Bays, 1 free
Software
- Windows 10 Professional 64-bit
- Clean install, no additional software
Chipset
- Intel X299 Chipset
Display Outputs
- 8 x DisplayPort 1.4
- Supports up to 4 monitors at once
- Supports HDCP
Graphics
- 2 x NVidia Quadro P5000 16B
Audio
- High Definition Audio, 5.1 or 7.1 channel
- Audio provided by Realtek ALC1220-VB Audio Chip on the motherboard
- ESS SABRE 9218 DAC chip
Input Devices
- No Keyboard or Mouse Included
Wired Networking
- 1 x Realtek 10/100/1000 LAN (Gigabit)
- 1 x Intel 10/100/1000 LAN (Gigabit)
Wireless Networking
- Gigabyte Wireless AC 867Mbps Wifi with Bluetooth 5.0
Power Supply
- 1000 watts, high efficiency (87%), Modular.
Dimensions
- Height: 585mm
- Width: 243mm
- Depth: 577mm
Interfaces
- 1 x PS/2 Keyboard or Mouse Port
- 2 x USB 2.0 Port (front)
- 8 x USB 3.1 Port (2 front, 6 rear)
- 2 x USB 3.1 Gen 2 Port (1 rear Type-C & 1 rear Type-A)
- 2 x RJ-45 Ethernet Port
- 2 x Thunderbolt 3 Ports 40Gb/s Bi-Directional Bandwidth
- 6 x Audio Jacks at the rear including S/PDIF
- 2 x Audio Jacks at the front
- 8 x DisplayPort 1.4 on video cards
- 2 x DL-DVI via adapter
Note the display outputs from the motherboard are disabled when a graphics card is installed
Expansion
- 4 x PCI-e x 16 Slots, 0 free
- 0 x PCI-e x 1 Slots
Case
- Be Quiet! Dark Base 900 Silent Black ATX Case
- 3 x 140mm Pre-installed fans
- Space for 4 additional 120/140mm fan
- Space to accept 120/140/240/280/360mm liquid coolers
Warranty
- 3 Year Return to Base parts and labour
- 1st 30 days collect and return at our expense
