Intel Core Ultra 7 270K Plus 3.7/5.5GHz 24 Core CPU

Intel Core Ultra 7 270K Plus 3.7/5.5GHz 24 Core CPU

An unlocked 24-core Arrow Lake processor for LGA1851 with fast DDR5 support, integrated Intel graphics and an on-chip NPU.

The Core Ultra 7 270K Plus is part of Intel’s Core Ultra Series 2 refresh for desktop, built on TSMC’s N3B process. It combines eight Performance-cores with sixteen Efficient-cores for 24 cores and 24 threads, with a 3.7GHz P-core base clock and a maximum turbo of 5.5GHz. It is aimed at enthusiast gaming PCs, content creation systems and demanding multitaskers who want a high core count with Intel’s current platform features.

Performance

The P-cores reach up to 5.4GHz and the E-cores up to 4.7GHz, with Intel’s scheduling directing foreground work to the fast cores and background tasks to the efficient ones. A 36MB Intel Smart Cache and a large 40MB of total L2 cache keep data close to the cores. As a K-series part the multiplier is unlocked for overclocking on a Z-series board, and Intel AI Boost provides a neural processing unit for AI-accelerated software.

Platform and connectivity

The 270K Plus fits the LGA1851 socket and supports dual-channel DDR5 at up to 7200 MT/s, with a maximum of 256GB. It provides 24 PCIe lanes across PCIe 5.0 and 4.0 for a graphics card and Gen 5 NVMe storage. Integrated Intel Graphics with four Xe-cores can drive displays directly, useful for productivity systems or as a fallback. Punch can fit it in a new LGA1851 build with a suitable board and DDR5 memory.

Cooling and noise

Intel rates the processor at 125W base power and 250W maximum turbo power, with a 105°C maximum operating temperature and a PCG 2020A thermal solution specification. No cooler is included, so a high-performance air cooler or a 240mm or larger liquid cooler is recommended to sustain turbo clocks quietly.

Ideal for

• High-end gaming PCs with a dedicated graphics card
• Content creation, streaming and heavy multitasking
• Enthusiasts who want an unlocked processor on Intel’s current LGA1851 platform

Specifications

• Model: Intel Core Ultra 7 processor 270K Plus
• Code name: Arrow Lake; lithography TSMC N3B
• Total cores / threads: 24 (8 P-cores + 16 E-cores) / 24
• Max turbo frequency: 5.5 GHz
• P-core max turbo / base: 5.4 GHz / 3.7 GHz
• E-core max turbo / base: 4.7 GHz / 3.2 GHz
• Cache: 36 MB Intel Smart Cache; total L2 cache 40 MB
• Processor base power / maximum turbo power: 125 W / 250 W
• Max operating temperature: 105°C
• Socket: FCLGA1851
• Unlocked: Yes (K-series)
• Memory: DDR5 up to 7200 MT/s, dual channel, max 256 GB
• PCI Express: 5.0 and 4.0, 24 lanes
• Integrated graphics: Intel Graphics, 4 Xe-cores
• NPU: Intel AI Boost
• Thermal solution specification: PCG 2020A
• Cooler included: None
• Launch: Q1 2026
