Antec C5 Mid-Tower Case, Tempered Glass, No Fans, Black
The Antec C5 chassis without the bundled fans: the same 270-degree glass dual-chamber design, ready for the cooling of your choice.
The C5 places the power supply and cables in a side chamber so the main compartment holds only the motherboard, graphics card and cooling behind two 4mm tempered glass panels that meet at a bevelled front corner. This version is supplied with no fans fitted, which suits builders who already have a preferred fan set or plan a liquid-cooled system with its own radiator fans. It supports ATX, Micro-ATX and ITX boards including back-connect designs.
Cooling and clearances
The chassis takes up to ten 120mm fans with a bottom-to-top airflow path. Radiators up to 360mm fit on the top and bottom and up to 280mm on the side, with a 120mm rear position. Graphics cards to 410mm, CPU coolers to 160mm and power supplies to 240mm including cables all fit, and magnetic dust filters cover the top and bottom.
Storage and I/O
One 3.5in and two 2.5in drive mounts, seven expansion slots and a front panel with two USB 3.0 ports, USB-C 3.2 Gen 2 and audio complete the layout. Punch can fit the C5 in a new build with a fan or radiator set chosen to match.
Ideal for
- Builders supplying their own fans
- 360mm liquid-cooled gaming PCs
- Back-connect motherboard builds
Specifications
- Form factor: Mid-tower, dual chamber
- Motherboard support: ATX, Micro-ATX, ITX
- Dimensions: 469mm D x 285mm W x 400mm H
- Materials: steel, plastic, 4mm tempered glass
- Max GPU length: 410mm
- Max CPU cooler height: 160mm
- Max PSU length: 240mm (including cables)
- Fans included: none
- Fan mounts: top 3x 120 / 2x 140mm, side 3x 120 / 2x 140mm, bottom 3x 120mm, rear 1x 120mm
- Radiator support: top 120/140/240/280/360mm, side 120/140/240/280mm, bottom 120/240/360mm, rear 120mm
- Drive bays: 1x 3.5in, 2x 2.5in
- Expansion slots: 7
- Front I/O: 2x USB 3.0, 1x USB-C 3.2 Gen 2, microphone, HD audio
- Colour: black
