Lian Li Vector V100 RX Mid-Tower Case, 4 ARGB Fans, Black

Lian Li Vector V100 RX Mid-Tower Case, 4 ARGB Fans, Black

A 270-degree glass mid-tower with four fans fitted, an integrated ARGB light strip and a front-side cable chamber.

The Vector V100 RX is Lian Li’s fan-included version of the V100. Two 4mm tempered glass panels wrap the front and side for an unobstructed view, three 120mm fans are pre-installed as side intakes and a fourth at the rear exhaust, and a 26-LED ARGB strip runs along the chassis. A dedicated chamber on the front side of the case hides cables with a tool-free management system, and a GPU support bracket comes pre-installed. It suits gaming builds that want the panoramic look with cooling sorted from the start.

Cooling and clearances

Up to nine fans fit: three 120mm or two 140mm on top, three 120mm on the side, two 120mm at the bottom and one at the rear, with the top taking radiators up to 360mm (under 60mm thick). Graphics cards up to 420mm and CPU coolers up to 178mm are supported, and ATX power supplies under 220mm fit.

Layout

Storage is one 2.5in SSD behind the tray and one 3.5in HDD at the bottom, with seven PCIe slots. Back-connect ATX and Micro-ATX boards are supported. Front I/O offers two USB 3.0 ports, USB 3.1 Type-C, audio and power and reset buttons. Punch can build a complete PC in the V100 RX with the lighting synced to your motherboard.

Ideal for

• Gaming PCs with fans and lighting included
• Back-connect motherboard builds
• Panoramic glass showcase systems

Specifications

• Model: V100RX
• Form factor: Mid-tower
• Motherboard support: ATX, Micro-ATX, Mini-ITX; back-connect ATX / Micro-ATX
• Dimensions: 446mm L x 235.5mm W x 484.65mm H
• Max GPU length: 420mm
• Max CPU cooler height: 178mm
• PSU: ATX, under 220mm
• Fans included: 3x 120mm side, 1x 120mm rear (pre-installed)
• Fan mounts: top 3x 120 / 2x 140mm, side 3x 120mm, bottom 2x 120mm, rear 1x 120mm (9 total)
• Radiator support: top up to 360mm (under 60mm thick)
• Drive bays: 1x 2.5in, 1x 3.5in
• Expansion slots: 7
• Front I/O: 2x USB 3.0, 1x USB 3.1 Type-C, audio, power, reset
• Panels: dual 4mm tempered glass (front and side)
• Lighting: integrated ARGB strip, 26 LEDs
• GPU support bracket: pre-installed
• Colour: black
• Warranty: case 1 year, fans 2 years
