High performance for professional video editing
Our high end video editing system offers a high power system based on the Intel high end desktop platform and is aimed at those who prefer the Intel platform over AMD. Whilst the Intel processors can’t keep up with the latest AMD chips, they give a pretty close fight and some software applications can still favour Intel hardware, even at the high end. The processor is the latest 10th generation model with 14 cores and 28 threads. The GPU is the RTX 3080 with 10GB of video memory. This rig is able to power through 4K, 5K and 6K content.
The addition of Thunderbolt 3 provides a very high bandwidth interface for use with external storage and even external GPU. The data transfer speeds over thunderbolt are up to 4 times faster than via regular USB 3.0.
The 1TB ADATA SX8200 PRO scratch drive offers one of the highest performance currently available with any SSD. This system also sees storage increase to 8TB and as we are using the Ironwolf Pro drive, write performance is maintained at a very high level, even for very large amounts of data being written to the drive. The power supply is also increased to 850w output.
The NVidia RTX 3080 GPU configuration in this system offers a significant increase in performance over the RTX 3070 model. A significant amount of the video editing workload is carried out on the GPU so by utilising this high performance card, the processing power of the GPU significantly reduces render times. This is ideal for real time processing of high resolution content in HDR. Coupled with the 14 core processor and X299 platform, this system is able to process seriously quickly.
Take a look at our blogs to find out more about how your choice of PC components affects your overall system performance in Premier Pro.
280mm Corsair Liquid Cooler
Core i9-10940X 14 Core CPU
Specification
Processor
- Intel Core i9-10940X 3.3Ghz 14 Core CPU,
- Max Turbo Frequency 4.8Ghz
- Cache: 19.25MB
- Corsair H115i 280mm Liquid Cooler Installed
Memory
- 64GB DDR4 3200Mhz Corsair RAM
- Quad Channel – 4 x 16GB
- Supports up to 128GB
- 8 x DIMM sockets (4 Used)
Hard Drive
- 512GB ADATA SX8200 NVMe M.2 SSD
- 1TB ADATA SX8200 NVMe M.2 SSD
- 2 x M.2 sockets, 0 free
- 8TB Seagate Ironwolf Pro 3.5″ Hard drive
- 8 SATA Ports, 6 free (1 used for 8TB HDD)
Optical Drive
- None
- No Optical Bays
Software
- Windows 10 Home 64-bit
- Clean install, no additional software
Chipset
- Intel X299 Chipset
Display Outputs
- 3 x DisplayPort 1.4
- 1 x HDMI 2.0b
- Supports up to 4 monitors at once
- Supports HDCP
Graphics
- NVidia RTX 3080 10GB
Audio
- High Definition Audio, 5.1 or 7.1 channel
- Audio provided by Realtek ALC1220 Audio Chip on the motherboard
Input Devices
- No Keyboard or Mouse Included
Wired Networking
- 1 x Intel 10/100/1000 LAN (Gigabit)
Wireless Networking
- Intel Wireless-AC 9560 via Gigabyte WB1733D-I
- Speeds up to 1733mbps
- Bluetooth 5.0
Power Supply
- 1000 watts, high efficiency (87%), Modular.
Dimensions
- Height: 481mm
- Width: 240mm
- Depth: 532mm
Interfaces
- 1 x PS/2 Keyboard or Mouse Port
- 1 x USB 2.0 Port (front)
- 8 x USB 3.1 Port (2 front, 6 rear)
- 2 x USB 3.1 Gen 2 Port (rear)
- 1 x RJ-45 Ethernet Port
- 2 x Thunderbolt 3 Ports 40Gb/s Bi-Directional Bandwidth
- 6 x Audio Jacks at the rear
- 2 x Audio Jacks at the front
- 3 x DisplayPort 1.4 on video card
- 1 x HDMI 2.0b on video card
- 1 x USB Type-C on video card
Expansion
- 5 x PCI-e x 16 Slots, 2 free
Case
- Be Quiet! Silent Base 601 Silent Black/Silver ATX Case
- 2 x 140mm Pre-installed case fans
- Space for 2 additional 120/140mm fan
- Space to accept 120/140/240/280/360mm liquid coolers
Warranty
- 3 Year Return to Base parts and labour
- 1st 30 days collect and return at our expense
- Be Quiet! Silent Base 601 Silver ATX C…
- Intel Core i9-10940X 3.3GHz 14 Core CPU with 4.8GHz Turbo
- Gigabyte X299 UD4 Pro Motherboard
- NVidia GeForce RTX 3080 10GB GDDR6X GPU
- 64GB CORSAIR VENGEANCE LPX 3200MHz (4x16GB)
- 512GB ADATA SX8200 PRO M.2 NVMe (3500MB/R, 2300MB/W) – 6x faster than SATA SSD
- 1TB ADATA SX8200 PRO M.2 NVMe (3500MB/R, 3000MB/W) – 6x faster than SATA SSD
- 8TB Seagate 3.5″ Ironwolf Pro HDD, 2 Years Rescue+DataRecovery on registration
- Corsair iCUE H115i RGB PRO XT 280mm Processor Liquid Cooling
- Corsair RM1000x 1000W 80 Plus Gold Fully Modular PSU
- 1733mbps 802.11ac 2.4 / 5GHz Dual Band PCIe Wi-Fi 5 / Bluetooth 5 Adapter
- Integrated Sound Card On The Motherboard
- Gigabyte Thunderbolt 3 Intel DSL7540 Titan Ridge
- Microsoft Windows 10 Home | Get a free upgrade to Windows 11¹ (when available, see below)
