Ultimate performance for professional video editing
This system represents the pinnacle of performance and current technology in our video editing range. The processor and GPU set up offer very high performance and the 128GB of memory is ideal for handling complex multi layer 8k workloads in HDR. It is possible to further upgrade the GPU to dual RTX 6000 if required.
The 2 x 16TB hard drives can be configured to operate in RAID 0 to boost performance and offer one 32TB volume. The 1TB Samsung 970 PRO scratch drive and 512GB 970 PRO application drive are the best performing drives on the market. There is also a further 2TB 970 EVO drive for larger projects.
The graphics performance is improved with the use of 2 x NVidia Quadro RTX 5000 GPU, each with a phenomenal 16GB of VRAM. This system is able to easily handle the most complex workloads.
Specification
- Intel Core i9-10940X 3.3Ghz 14 Core CPU
- Max Turbo Frequency 4.8Ghz
- Cache: 19.25MB
- Corsair H150i Pro 360mm Liquid Cooler Installed
Memory
- 128GB DDR4 3200Mhz RAM
- Quad Channel – 4 x 32GB
- Supports up to 256GB
- 8 x DIMM sockets (4 Used)
Hard Drive
- 512GB Samsung 970 Pro NVMe M.2 SSD
- 1TB Samsung 970 Pro NVMe M.2 SSD
- 2TB Samsung 970 EVO NVMe M.2 SSD
- 3 x M.2 sockets, 0 free
- 2 x 16TB Seagate Ironwolf Pro 3.5″ Hard drives
- 8 SATA Ports, 5 free (3 Used for Blu Ray & 2 x 16TB HDD)
Optical Drive
- Asus BW-16D1HT Blu Ray Writer
- 2 x Optical Bays, 1 free
Software
- Windows 10 Professional 64-bit
- Clean install, no additional software
Chipset
- Intel X299 Chipset
Display Outputs
- 8 x DisplayPort 1.4
- Supports up to 8 monitors at once
- Supports HDCP
Graphics
- 2 x NVidia Quadro RTX 5000 16GB
Audio
- High Definition Audio, 5.1 or 7.1 channel
- Audio provided by Realtek ALC1220-VB Audio Chip on the motherboard
- ESS SABRE9218 DAC chip
Input Devices
- No Keyboard or Mouse Included
Wired Networking
- 1 x Aquantia 10/100/1000/2500/5000 LAN (5Gbit)
- 1 x Intel 10/100/1000 LAN (Gigabit)
Wireless Networking
- Gigabyte Wireless AC 2400Mbps Wifi with Bluetooth 5.0
Power Supply
- 1200 watts, high efficiency Platinum (89%), Modular.
Dimensions
- Height: 585mm
- Width: 243mm
- Depth: 577mm
Interfaces
- 4 x USB 2.0 Port (2 front, 2 rear)
- 8 x USB 3.1 Port (2 front, 6 rear)
- 2 x USB 3.1 Gen 2 Port (1 rear Type-C & 1 rear Type-A)
- 2 x RJ-45 Ethernet Port
- 2 x Thunderbolt 3 Ports 40Gb/s Bi-Directional Bandwidth
- 6 x Audio Jacks at the rear including S/PDIF
- 2 x Audio Jacks at the front
- 8 x DisplayPort 1.4 on video cards
- 2 x DL-DVI via adapter
Note the display outputs from the motherboard are disabled when a graphics card is installed
Expansion
- 4 x PCI-e x 16 Slots, 0 free
- 0 x PCI-e x 1 Slots
Case
- Be Quiet! Dark Base 900 Silent Black ATX Case
- 3 x 140mm Pre-installed fans
- Space for 4 additional 120/140mm fan
- Space to accept 120/140/240/280/360mm liquid coolers
Warranty
- 3 Year Return to Base parts and labour
- 1st 30 days collect and return at our expense
