HAVN HS 420 Dual-Chamber White

HAVN HS 420 Dual-Chamber Mid-Tower Case White

A premium dual-chamber tower with a single curved glass panel, eleven 140mm fan positions and three 420mm radiator mounts.

The HAVN HS 420 in white is a large dual-chamber mid-tower for E-ATX, ATX, Micro-ATX and Mini-ITX motherboards. Its front and side are one continuous heat-formed sheet of tempered glass with a tight bend radius, so the view of the components is uninterrupted, and the second chamber behind the motherboard hides the power supply, drives and cabling. No fans are supplied; instead the case is set up to take up to eleven 140mm fans and three 420mm radiators. It is intended for high-end gaming and workstation builds where cooling and appearance both matter, and Punch can build a new system into it.

Cooling and airflow

There are eleven fan positions, every one accepting 120mm or 140mm fans: three in the roof, three on the right-hand side feeding air across the graphics card, three in the floor and two at the rear. Radiators of 280mm, 360mm or 420mm fit in the top, right side and bottom, with generous thickness allowances of 65mm at the top, 60 to 80mm at the side and 120mm at the bottom. Two six-way PWM splitters are included so up to twelve fans can be run from two motherboard headers, and the SimpliCable routing system keeps the wiring tidy in the rear chamber.

Clearances and storage

Graphics cards up to 480mm long and 195mm wide fit, and CPU air coolers up to 185mm tall. ATX power supplies up to 220mm long are supported, with 290mm of physical clearance. Storage mounts are split between the right fan bracket, which takes four 3.5in or eight 2.5in drives, and the cable tray, which takes one 3.5in or two 2.5in; four drive bays are supplied. Six expansion slots are provided.

Build and connectivity

The chassis is SGCC steel with tempered glass, ABS, nylon and zinc alloy fittings, and magnetic panel fixings. It weighs 17.84kg empty, so it needs a sturdy desk or floor position. The I/O panel has one USB 3.2 Gen 2 Type-C port, two USB 3.2 Gen 1 Type-A ports, an audio jack and power and reset buttons.

Ideal for

• High-end gaming builds with a 420mm or 360mm liquid cooler and a very large graphics card
• White showcase systems with an uninterrupted glass view
• Workstations on an E-ATX board that need plenty of drive space

Specifications

• Case type: Dual-chamber mid tower
• Colour: White
• Materials: SGCC steel, tempered glass, ABS, nylon, silicone, zinc alloy, magnets
• Motherboard support: E-ATX (max width 277 mm), ATX, Micro-ATX, Mini-ITX
• Dimensions (L x W x H): 541 x 259.5 x 547 mm
• Fans included: None; 2 x 6-way PWM splitters included
• Fan mounts: Top 3 x 120/140mm; right side 3 x 120/140mm; bottom 3 x 120/140mm; rear 2 x 120/140mm (up to 30 mm thick)
• Radiator support: Top 280/360/420mm (65 mm max thickness); right side 280/360/420mm (60-80 mm); bottom 280/360/420mm (120 mm)
• Max graphics card length: 480 mm; max width 195 mm
• Max CPU cooler height: 185 mm
• Max PSU length: 220 mm (ATX; 290 mm clearance)
• Drive bays: 4 x 3.5in or 8 x 2.5in (right fan mount) plus 1 x 3.5in or 2 x 2.5in (cable tray); 4 bays supplied
• Expansion slots: 6
• Front I/O: 1 x USB 3.2 Gen 2 Type-C, 2 x USB 3.2 Gen 1 Type-A, 1 x audio jack, power and reset
• Panels: UniSheet heat-formed panoramic tempered glass front/side
• Net weight: 17.84 kg
