Thermalright Silver Soul 110 White Dual-Tower CPU Cooler

Thermalright Silver Soul 110 White Dual-Tower CPU Cooler

A white dual-tower air cooler only 110mm tall, built for small-form-factor cases that cannot take a full-height tower.

The Silver Soul 110 takes the twin fin stack layout of Thermalright’s larger coolers and shrinks it to a 94 x 94 x 110mm footprint. Five 6mm heat pipes run from a nickel-plated C1100 copper base through two aluminium towers, with a 92mm fan sandwiched between them. At 400g it is light enough for a small board and low enough for many ITX and slim micro-ATX cases, and the white finish suits light-coloured builds.

Fan and noise

The Thermalright TL-B9W fan is 92 x 92 x 25.6mm and runs up to 2500 RPM under PWM control. It moves 54 CFM at 2.24mm-H2O static pressure, which is high for a 92mm fan and lets it push air through both fin stacks. Thermalright quotes 23 dBA, and the S-FDB bearing keeps it running smoothly over its life.

Compatibility

Mounting kits cover Intel LGA115X, 1200, 1700, 1851, 2011, 2011-3 and 2066 and AMD AM4 and AM5. It is a good match for Core i5 and Ryzen 5 and 7 processors in compact systems where a stock cooler is too loud. Punch Technology can fit it in a new small-form-factor build on request.

Ideal for

• Mini-ITX and slim micro-ATX cases
• White or light-themed builds
• Core i5, Ryzen 5 and Ryzen 7 systems

Specifications

• Type: Dual-tower air cooler
• Colour: White
• Socket support: Intel LGA115X, 1200, 1700, 1851, 2011, 2011-3, 2066; AMD AM4, AM5
• Heatsink dimensions: 94 x 94 x 110mm (L x W x H)
• Heatsink weight: 400g
• Heat pipes: 5 x 6mm
• Fins: 0.4mm thick, 1.6mm gap
• Base: C1100 pure copper, nickel plated
• Fan: Thermalright TL-B9W, 92 x 92 x 25.6mm, 105g
• Fan speed: 2500 RPM (plus or minus 10%) max
• Airflow: 54 CFM max
• Static pressure: 2.24mm-H2O max
• Noise: 23 dBA
• Bearing: S-FDB
• Fan connector: 4-pin PWM, 0.13A
