Cooler Master MWE Gold 1050 V2 ATX 3.1 1050W Fully Modular Power Supply

Cooler Master MWE Gold 1050 V2 ATX 3.1 1050W Fully Modular Power Supply

A 1050W Gold-rated, fully modular supply with a native 12V-2×6 connector, a 140mm fan and a ten-year warranty.

The MWE Gold 1050 V2 ATX 3.1 sits at the top of Cooler Master’s MWE range and is aimed at gaming PCs and workstations that pair a high-end graphics card with a powerful processor. It meets the ATX 3.1 standard, so it is designed to handle the peak power draw of current RTX-class cards, and it carries the 12V-2×6 connector those cards use, along with three conventional 6+2-pin PCIe leads for other hardware.

Gold efficiency and a 50°C rating

Certified 80 Plus Gold with efficiency of 90% or better at typical load, the unit runs cool and is rated for full output at ambient temperatures up to 50°C, which gives useful margin in a warm case or a hot room. High-quality Japanese capacitors are used throughout and Cooler Master backs the supply with a ten-year warranty.

Quiet 140mm fan

A 140mm fan on a fluid dynamic bearing moves plenty of air at low speed, so the unit stays quiet under normal desktop and gaming loads. The fully modular, flat black cables make for a tidy build with unobstructed airflow, and Punch can fit and route them in any new system we build.

Plenty of connections

Two CPU connectors (one 4+4-pin and one 8-pin), twelve SATA connectors and four peripheral connectors mean it will cope with dual-EPS motherboards and a large drive array without adaptors.

Ideal for

• High-end gaming PCs with a 12V-2×6 graphics card
• Content-creation workstations with many drives
• Systems that will be upgraded over a long life

Specifications

• Model: MPE-A501-AFCAG-3E (UK cable variant -3EUK)
• Rated output: 1050W
• Standard: ATX Rev. 3.1
• Efficiency: 80 Plus Gold, 90% or better at typical load
• Form factor: ATX
• Cabling: Fully modular, flat black cables
• Fan: 140mm, fluid dynamic bearing
• ATX 24-pin: 1
• CPU: 1x 4+4-pin, 1x 8-pin
• PCIe 12V-2×6: 1
• PCIe 6+2-pin: 3
• SATA: 12
• Peripheral 4-pin: 4
• Input: 100-240V, 50-60Hz
• Protections: OVP, OPP, SCP, OCP, UVP, OTP, inrush protection
• Operating temperature: 0-50°C
• Capacitors: Japanese
• Dimensions: 180 x 150 x 86mm
• Warranty: 10 years
