High end performance for CPU intensive applications
A high performance PC workstation designed to excel at highly threaded workloads, this system really performs well in professional productivity software. This system is ideal for multiple tasks including video editing and rendering, 3D modelling, content creation, transcoding, ray tracing, digital audio encoding, running virtual machines and many engineering and scientific applications.
The AMD Ryzen Threadripper processor offers a very large number of cores and threads and therefore can handle many processes running concurrently, reducing compute time for CPU intensive workloads.
AMD Threadripper Processor
Specification
Processor
- AMD Ryzen Threadripper 2920X 12 Core 3.5GHz CPU
- 12 Cores / 24 Threads
- Max Turbo Frequency 4.3Ghz
- Cache: 32MB
- Corsair H100i Pro Liquid Cooler Installed
Memory
- 32GB DDR4 3200Mhz AMD Optimised RAM
- Quad Channel – 4 x 8GB
- Supports up to 128GB
- 8 x DIMM sockets (4 Used)
Hard Drive
- 256GB ADATA SX8200 Pro NVMe M.2 SSD
- 3 x M.2 sockets, 2 free
- 8 SATA Ports, 8 free
Optical Drive
- None
- 1 x Optical Bay, 1 free
Software
- Windows 10 Professional 64-bit
- Clean install, no additional software
Chipset
- AMD X399 Chipset
Display Outputs
- 4 x mini-DisplayPort
- Supports up to 4 monitors at once
- Supports HDCP
Graphics
- AMD Radeon Pro WX3200 4GB Professional GPU with 10 bit colour
Audio
- High Definition Audio, 5.1 or 7.1 channel
- Audio provided by Realtek ALC1220 Audio Chip on the motherboard
Input Devices
- No Keyboard or Mouse Included
Wired Networking
- 1 x Intel 10/100/1000 LAN (Gigabit)
Wireless Networking
- Not Included
Power Supply
- 650 watts
- Contour 650W 87% Efficient Modular
Dimensions
- Height: 445mm
- Width: 220mm
- Depth: 492mm
Interfaces
- 1 x PS/2 Keyboard or Mouse Port
- 2 x USB 3.1 Gen 1 Port and 1 x USB 2.0 at the front
- 8 x USB 3.1 Gen 1 Port at the rear
- 2 x USB 3.1 Gen 2 Port (1 x Type-C & 1 x Type-A at the rear)
- 1 x RJ-45 Ethernet Port
- 6 x Audio Jacks at the rear including S/PDIF out
- 2 x Audio Jacks at the front
- 4 x mini DisplayPort on video card
Note the display outputs from the motherboard are disabled when a graphics card is installed
Expansion
- 5 x PCI-e x 16 Slots, 4 free (1 x Used for video card)
Case
- Be Quiet! Pure Base 600 Black ATX Case
- 1 x 140mm pre-installed fans at the front
- 1 x 120mm pre-installed fan at the rear
- Space for 3 additional 120/140mm fans
- Space to accept 120/140/240/280/360mm liquid coolers
Warranty
- 3 Year Return to Base parts and labour
- 1st 30 days collect and return at our expense
- Be Quiet! Pure Base 600 Black ATX Case
- AMD Ryzen Threadripper 2920X CPU 12 Core 3.5/4.3GHz
- Gigabyte X399 AORUS PRO AMD Threadripper TR4 Motherboard
- AMD Radeon Pro WX 3200 4GB (10-bit colour)
- 32GB CORSAIR VENGEANCE LPX 3200MHz (4x8GB)
- 256GB ADATA SX8200 PRO M.2 NVMe (3500MB/R, 1200MB/W) – 6x faster than SATA SSD
- Corsair Hydro Series H100i PRO RGB 240mm TR4 Processor Liquid Cooler
- Contour 650W ATX 87+ Modular Power Supply GPU650V-G
- Integrated Sound Card On The Motherboard
- Microsoft Windows 10 Professional 64 Bit
